Derivative of the Sigmoid function

Image for post
Sigmoid and Dino

In this article, we will see the complete derivation of the Sigmoid function as used in Artificial Intelligence Applications.

To start with, let’s take a look at the sigmoid function

Image for post
Sigmoid function

Okay, looks sweet!
We read it as, the sigmoid of x is 1 over 1 plus the exponential of negative x.
And this is the equation (1).

Let’s take a look at the graph of the sigmoid function,

Image for post
Graph of the Sigmoid Function

Looking at the graph, we can see that the given a number n, the sigmoid function would map that number between 0 and 1.
As the value of n gets larger, the value of the sigmoid function gets closer and closer to and as n gets smaller, the value of the sigmoid function is get closer and closer to 0.

Okay, so let’s start deriving the sigmoid function!
So, we want the value of

Image for post
Step 1

In the above step, I just expanded the value formula of the sigmoid function from (1)

Next, let’s simply express the above equation with negative exponents,

Image for post
Step 2

Next, we will apply the reciprocal rule, which simply says

Image for post
Reciprocal Rule

Applying the reciprocal rule, takes us to the next step

Image for post
Step 3

To clearly see what happened in the above step, replace u(x) in the reciprocal rule with (1 + e^(-x)) .

Next, we need to apply the rule of linearity, which simply says

Image for post
Rule of Linearity

Applying the rule of linearity, we get

Image for post
Step 4

Okay, that was simple, now let’s derive each of them one by one.
Now, derivative of a constant is 0, so we can write the next step as

Image for post
Step 5

And adding 0 to something doesn’t effects so we will be removing the 0 in the next step and moving with the next derivation for which we will require the exponential rule, which simply says

Image for post
Exponential Rule

Applying the exponential rule we get,

Image for post
Step 6

Again, to better understand you can simply replace e^u(x) in the exponential rule with e^(-x)

Next, by the rule of linearity we can write

Image for post
Step 7

Derivative of the differentiation variable is 1, applying which we get

Image for post
Step 8

Now, we can simply open the second pair of parenthesis and applying the basic rule -1 * -1 = +1 we get

Image for post
Step 9

which can be written as

Image for post
Step 10

Okay, we are complete with the derivative!!

But but but, we still need to simplify it a bit to get to the form used in Machine Learning. Okay, let’s go!

First, let’s rewrite it as follows

Image for post
Step 11

And then rewrite it as

Image for post
Step 12

And since +1 — 1 = 0 we can do this

Image for post
Step 13

And now let’s break the fraction and rewrite it as

Image for post
Step 14

Let’s cancel out the numerator and denominator

Image for post
Step 15

Now, if we take a look at the first equation of this article (1), then we can rewrite as follows

Image for post
Step 16

And with that the simplification is complete!

So, the derivative of the sigmoid function is

Image for post
Derivative of the Sigmoid Function

And the graph of the derivative of the sigmoid function looks like

Image for post
Graph of Sigmoid and the derivative of the Sigmoid function
